Uv-Vis-Nir Spectrometer

The AvaSpec-Mini4096CL, a 4096-pixel CMOS array miniature spectrometer, was one of the most eagerly anticipated product releases of 2018. Please attend one of our forthcoming trade shows to witness the extraordinary resolution of this instrument in person, or contact us for additional details.input:
output:AvaSpec-Mini(CL): CMOS Insideinput:
output:Avantes is enthusiastic about the imminent release of the next generation of AvaSpec-Mini spectrometers, which will feature advanced electronics and communications, as well as CMOS detectors. The CL series, which is no larger than a deck of cards, exhibits exceptional temperature and wavelength stability, similar to the original AvaSpec-Mini. This instrument is well-suited for handheld applications and is portable.input:
output:Technical Data:input:
output:
Stray light – 0.2% to 1%

Sensitivity in counts/µW per ms integration time – 261,000

Detector – HAM S13496, CMOS linear array, 4096 pixels (7 x 200 µm)

Signal-to-noise ratio: 300:1

AD converter – 6 MHz, 16 bits

Integration time – 30 µs to 50 sInterface: USB 2.0 (480 Mbps), pigtailed (40 cm) USB-ASample rate with on-board averaging: 6.5 ms/scan8.9 ms/scan for data transfer.I/O – 5 bidirectional programmable I/O; 1 analog out; 1 analog in; 1 x 5 VPower supply: 500 mA, default USB power
