Treadmill Ergometer With Handrails
| Options And Accessories | With Handrails, With Incline |
| Patient Type | Pediatric |
Exercise ECG tests and cardiology rehabilitation can be conducted with a reliable device that includes an ECG module. The treadmill’s primary attributes include:the ability to set a precise load during training and stress exercise examinations, as well as three safety switch-off buttons.Key Features
LxWxH – 1999 x 747 x 1217 mmWeight: 185 kg (excluding packaging)
The running belt’s useful dimensions are 1500 x 500 mm.
The power consumption and supply voltage are both 230 V and 50 Hz, with a current of less than 10 A.
Inclination angle of 0-25 % with a 0.5 % gradient
The maximum weight of a patient is 180 kg.
Two safety switches are located on the handrails, and an external switch is optional.
RS-232 and USB communication interfaces
ECG-Modul: Measurement bandwidth: 0.05-150 Hz
ECG-Modul: Measurement error is less than 2.0%
ECG-Modul: Quantization at 2.50 µV/bitECG-Modul: Sampling rate of 8000 Hz per channelECG-Modul: Frequency of packages: 200, 250, 400, and 500 HzCG-Modul: Transmission speed: 19200, 28800, 38400, 57600, and 115200 bps.ECG-Modul: Power line filter, 50 Hz; 60 HzECG-Modul: Filter for muscle interferences at 25, 35, and 45 Hz.ECG-Modul: Isoline filter at 0.15, 0.45, 0.75, and 1.50 HzQRS detection lead: ECG module Selection of: I; II; III; aVR; aVL; aVF; V1; V2; V3; V4; V5; V6
ECG-Modul: HR measurement range: 25-300 bpmHR frequency: 1 bpm ECG-ModuleECG-Modul: HR measurement error is less than 2.0%
Safety of use EN 60601-1; EN 957-1; EN 957-6 Electromagnetic compatibility EN 60601-2Medical device class IIa (rule 10)Class I protection against electric shock (EN 60601-1)Training equipment classification (EN 957-1): Class SA
