Tabletop Patient Monitor

In 2024, Winner of the German iF Design Award and the Red Dot Award. An innovative tablet vital signs monitor with a 10 high-resolution touch screen, built-in camera scanner, and detachable base that is particularly suitable for scenarios such as triage centers, ward rounds, and emergency care. The medical staff can effortlessly transition between the round mode and spot-check mode based on the situation. In addition to providing basic vital signs monitoring, the device also offers assistant decision-making tools, including automatic ECG diagnosis and Early Warning Score, to assist medical staff in rapidly assessing the patient’s real-time health status and estimating the associated health risks. Additionally, the information interconnection can be achieved by connecting it to third-party systems, such as HIS or EMR, using the HL7 protocol.input:
output:
Physical Characteristics

main unit dimensions: 257 mm x 193.5 mm x 28.3 mm

Color LCD screen with a multi-touch capacitive touch panel, measuring 1280×800.Main Unit Indicators

Power/switch indicator: 1 (white, yellow, and green)input:
output:Individual: QRS tone and key tone are supported. Provide support for pitch tone and multi-level tone modulation.input:
output:Connectors for the primary unitOne adapter connector that is multifunctional:
NIBP cuff connector: 1
Connector for power adapter: One One PogoPin connector is included.One USB connector is included.Camera: Color CMOS camera, 8 MPixels, 3264×2448input:
output:Base connectorsNumber of USB connectors: 3One PogoPin connector is required for communication with the primary unit.One temperature probe connector is included.Thermal recorderRecorder Indicator: One power indicator (Green) and one error indicator (Red)Horizontal resolution: 8 dots per millimeter Vertical resolution: 8 dots per millimeterPaper width: 50 mm ± 1 mmPaper speed: 25 mm/s and 50 mm/s
