Sterilizer Steam Generator

Your sterilizer may be utilized in conjunction with an MMM steam generator in the event that a pure steam supply is unavailable on the premises. The steam generator can be installed adjacent to, above, or away from the steam consumer, or it can be integrated into the sterilizer, regardless of the layout of your facilities. The sterilizer control panel provides a convenient interface for operating the steam generator.input:
output:The technical highlights include:input:
output:The boiler’s performance can be optimized to meet the needs of the connected consumer in 9 kW increments, ranging from 36 to 81 kW.input:
output:
Thermal degassing is done to decrease the amount of non-condensible gases in the steam.input:
output:Requires minimal electrical power when connectedinput:
output:Rated power: 36 to 54 kW or 63 to 81 kWinput:
output:Pressure limiter: 3.2 barinput:
output:For a pure steam supply that is independentThe Unotherm II is a pure steam generator that provides exceptional performance while consuming minimal energy. It has been specifically engineered for facilities that lack a central steam supply. Additionally, it can be employed to generate steam at a reasonable cost during weekends or emergencies. The boiler output can be optimized to satisfy the unique needs of the connected sterilizer.For instance, in order to minimize the amount of non-condensable gases in the sterilization steam, the boiler feed water undergoes thermal degassing in a process that is monitored and controlled by a temperature sensor. Automatic blow-down ensures that the boiler water’s quality remains consistently high. Conductance-controlled blow-down is an alternative. This completely eliminates the possibility of performance being impacted by corrosion and deposits.
