Semi-Automatic Filler

Capable of dispensing a broad range of fill volumes, from.05ml to 260ml

Models that are suitable for use in hazardous environments

Stainless steel construction, compact design.

It is effortless to establish, operate, clean, and replace.

Compressed air is not necessary for the majority of applications; 110V operation is sufficient.The FILAMATIC® AB Series Benchtop is a medium-duty filler that is semi-automatic and designed for the repetitive dispensing of liquids ranging from water-thin to viscous, as well as molten products and products containing small particulates. The AB Series is capable of accommodating fill volumes ranging from.05 to 260ml, and it allows for the mixing and matching of pumps and nozzles to achieve the highest level of flexibility and versatility.input:
output:The crankshaft of this single-nozzle filling machine is rotated by a variable-speed electrical gearmotor drive, which powers a volumetric piston pump referred to as a "Filling Unit." The Filling Units are accessories that are available to dispense a diverse selection of liquids. They are constructed from either stainless steel or glass. The AB Series is available in three models, each of which operates at a maximum speed of 84 RPM, 35 RPM, and 23 RPM. The AB, AB-5, and AB-8 are the models. Designs are accessible for OEM applications, as well as CE Mark-certified and air-operated models for hazardous environments.
