Portable Patient Monitor
| Measured Parameter | Ecg, Resp, Temp, Etco2, Eeg, Nibp, Ibp, Spo2 |
| Configuration | Portable, Compact |
| Applications | Transport |
| Technology | Pulse Wave Analysis |
| Options And Accessories | With Touchscreen, With Built-In Printer, With Integrated Battery |
offers the first solution for the highest level of accuracy and functionality, thanks to its unparalleled performance and advanced technology.Detailsinput:
output:Multiple parameters of your request are presented in a straightforward pop-up menu.
The parameters are user-friendly and intuitive, allowing you to quickly and accurately monitor your vital signs.input:
output:Arrhythmia analysis.br/>Pacemaker detection.
ST Analysis.Lead-off Detection. Each function is distinguished by its user-friendliness and convenience.
Default four-screen configurations. Full-color LCD with exceptional visibility.
Hot keys that are effortless to operate. [Alarm, Screen, Freeze, NIBP Print. Exit].Networking capabilities are available. Multilingual capabilities are possible.Advanced NIBP with patient size selection for adults. Neonatology, pediatric. Accurate and proven SpO2 technology with real-time waveform display and optional EtCO2.Technical SpecificationsDISPLAY
Resolution 800 x 480
Trace 6 Max.
Sweep Speed 6.3/12.5/25mm/s
Indicator
battery charging LED, AC power LED, alarm supend LEDElectrocardiogram (ECG)ECG waveform 2Channel Input 3-lead / 5-lead (l, ll, lll, aVL, aVR, aVF, V)Sweep Speed: 6.4, 12.5, and 25 mm/sGain (Sensitivity) 5 / 10 / 15 mm/mV
20 to 300 beats per minute
The pulse accuracy is within ±2bpm.Lead-off Detection: YesYes Arrhythmia Analysis ST segment Analysis Pacemaker Detection RespiratoryMeasurement range: 2 to 150 rpm Resolution: 1 rpm Accuracy: ±2 rpmApnea delay: 10 to 60 seconds (in 1-second increments)
Apnea alarm NIBP
Operation mode: Manual
Automatic (2/510/15/30/60/120min)
Inflation pressure range: 0 to 300 mmHg Maximum inflation pressure:Adult: 300±5 mmHgNeonate: 150±5 mmHg
Resolution: 1 millimeter of mercury.Protection against excessive pressure Yes, an adult.Systolic (60 to 270),Diastolic (40 ~ 245) and mean (44 ~ 255)
