Po2 Blood Gas Analyzer

The Blood Gas Analyzer LBGS-A10 is capable of delivering results in under 90 seconds and necessitates a sample volume of only 120 µl for whole blood and 50 µl for capillary blood. The 10.4-inch TFT touchscreen has an intuitive interface that enables users to easily input data and access detailed results. It offers automatic calibration at both one and two points to ensure the highest level of precision. Whole blood, serum, plasma, dialysate, and cerebrospinal fluid (CSF) are all supported by our blood gas analyzer.Specifications

pH (CH) Measuring Range: 6,000 to 9,000 pH scale

pCO₂ Measuring Range – 1.607 to 26.67 kPa, 8.0 to 200.0 mmHg

pO₂ Measuring Range – 0 to 106.7 kPa, 0 to 800.0 mmHg

K Measuring Range – 0.5 to 15.0 mmol/LNa⁺ Measuring Range: 20.0 to 200.0 mmol/LCl⁻ Measuring Range – 20.0 to 200.0 mmol/LCa²⁺ Measuring Range: 0.3 to 5.0 mmol/LHCT Measuring Range: 12.0 to 65.0 percent

B.P. Measuring Range: 500 to 800 mmol/L
Samples include whole blood, serum, plasma, dialysate, and cerebrospinal fluid.

Input Parameters: Patient Temperature, Hemoglobin, FiO2, and Barometric Pressure

Calibration: Automatic, One-point, and Two-pointData Storage – Over 5000 ResultsDisplay: 10.4-inch TFT touch screenBattery: 24V Ni-MH battery with a capacity of 3.0Ah.Printer – Thermal Printer Built-InFeatures: – Infrared human detector – Barcode reader – various barcode typesQuick and user-friendly data entryEnergy-efficient standby mode

Comprehensive data management

Simple and adaptable calibrant cartridgeApplications

Intuitive user interface

`Blood gas analyzer LBGS-A10 is employed to quantify pH, blood gas (e.g., pCO2 and pO2), electrolytes, and metabolite parameters in combination from whole blood, serum, plasma, dialysate, and cerebrospinal fluid (CSF) in a variety of settings, including hospitals, medical facilities, research institutes, and laboratories.
