Pharmacy Refrigerator

Ensuring the efficient conservation of its products and inputs is a significant challenge for clinics, laboratories, hospitals, and immunization centers, among others.

Operational agility and safety were prioritized in the development of Fanem’s hemato-immuno conservation chambers. In the event of a power outage, the EBS battery system of this model allows for operation for a variety of hours in critical situations, thereby guaranteeing the highest level of temperature uniformity in comparison to other models on the market.input:
output:
Primary characteristics

• The internal structure can be thermoplastic or, at an alternative, 304 stainless steel, which is resistant to corrosion. The corners are rounded to facilitate cleaning and sterilization. The housing is constructed from chemically treated steel plates and is coated with a white epoxy paint.

• A transparent acrylic internal barrier with doors;• All walls are equipped with high-density polyurethane thermal insulation.• Internal capacity: 16,000 5-ml doses;
DAQ (Data Acquisition) – stores data in memory for a maximum of 10 days, enabling the subsequent examination of temperature fluctuations.• Cooling system that utilizes R600 hydrocarbon ecological gas, which is free of chlorofluorocarbons.NEVER-ENDING SYSTEM

Ensures that the fan operates continuously and does not disrupt the uniformity of internal temperature, even during power outages when battery mode is on.Triple sensorEquipment equipped with the standard “TRI-SENSOR” technology, which consists of three sensors: one that measures temperature and is immersed in a solution that simulates the actual temperature of the stored vaccine; another that is directly in the air for temperature control, allowing for a rapid response from the system; and a third that is connected to the safety thermostat and operates independently.
