Orbital Thermo-Shaker

The IKA Matrix Orbital is a member of a new and potent thermoshaker product family that is currently available. IKA Matrix Orbital is appropriate for variable inserts and mixes. In all laboratory applications, samples with even the smallest volumes mix reliably and completely, regardless of whether they are blood samples, pharmaceutical agents, DNA/RNA samples, or ELISA assays. An optimal mixing outcome and the absence of cross-contamination.input:
output:Furthermore, the IKA Matrix Orbital is equipped with a plethora of user-friendly features:input:
output:• The intuitive operation is facilitated by a large and clear display with a convenient menu structure.

• The liquid is mixed quickly and effectively with a shaker diameter of up to 3 mm and speeds of up to 3,000 rpm.

• Two distinct speed modes for optimal mixing

• Adjustment of the speed in accordance with the volume of filling, the insert, and the attachment• The housing is made of aluminum die cast, which guarantees secure positioning, exceptional stability, and everyday robustness.input:
output:Data TechnicalType of movement: orbitalShaker diameter: 3 millimetersMaximum load: 0.3 kgAllowable ON time: 100%

Minimum speed (adjustable): 300 revolutions per minuteTFT speed display

Speed deviation: 30 ± rpmSpeed control: 10 RPM incrementsTimer: YesTFT timer displayTime setting minimum: one second

The maximum time setting is 6000 minutes.Timer and continuous operation are the two operational modes.
Yes, I have experience working with microtiter plates.One microtiter plate is required.Reaction vessels: 24 x 0.5 ml, 24 x 1.5 ml, and 24 x 2.0 ml.One PCR plate is required.
Number of Deep Well Plates (DWP): 1Dimensions (W x H x D): 198 x 124 x 318 mmWeight: 7.2 kg
The permissible ambient temperature range is 5 to 40°C.Maximum permissible relative humidity: eighty percent

IP 21 is the protection class as defined by DIN EN 60529.RS-232 interface: Yes
