Optical Stereo Microscope

The Stereo Microscope with Reflected Light.input:
output:The Optimal Microscope for Medical and Technological Applications

The SOM 82 reflected light stereo microscope is optimally suited for mobile use, as it is directly mounted on a stable table using clamps or screws.input:
output:The pivot and swivel arm are both adjustable and suitable for use in larger work areas. Maintain an ergonomically correct and fatigue-free posture by adjusting the microscope’s position with a simple flick of the wrist.input:
output:
The perfect solution for nearly every application is provided by the combination of coordinated binocular tubes and eyepieces, as well as various magnification systems (3-fold, 5-fold, or 1:6 manual zoom).

Certainly, the SOM 82 can be equipped with a variety of camera and video systems, as well as an additional viewer facility.input:
output:The SOM 82 can also be supplied with a mounting device for wall or ceiling installation upon request.

The SOM 82 is shipped in an aluminum case. The microscope can be stored in a safe and space-saving manner when it is not in use.input:
output:The SOM 82 microscope is particularly well-suited for training and training centers due to its exceptional flexibility.

(Image used with the kind permission of Botzer Ergonomics) Technical Datainput:
output:IlluminationLED-illumination integrated (optional) Cold light illumination 15V / 150WObjective / Working Distancef = 100 mm, f = 150 mm, f = 175 mm, and f = 200 mm250 mm, 300 mm, 350 mm, and 400 mm are the values of f.Fine-tuning12 mm with a focus object at f = 250 mm and f = 300 mm,40 mm manualBinocular tubesStandard dimensions for straight tubes are 125 mm and 45° for inclined tubes.However, we can also provide a straight tube upon request with a diameter of 159 mm and an inclined tube with a diameter of 159 mm.45° or wide angle swivel tube f = 182 mm 0 – 210°
