Optical Profilometer

The NPFLEX-1000 floor-standing white light interferometer (WLI) provides the most precise and adaptable solution for the assessment of nano- to macro-features on large parts in precision machining QA/QC. A swivel head design with a 300 mm distance between the stage and objectives, a robust bridge architecture, and a large form-factor open-gantry are among the key features. This unique design enables the NPFLEX-1000 to accommodate the broadest range of sample sizes and shapes and to access the most difficult orientations.

NPFLEX-1000 provides the throughput and repeatability that operators require in dynamic sectors such as automotive, medical, and large-scale additive manufacturing, thanks to the ease-of-use advantages of our next-generation optical profiler technology and this unique design. It is capable of measuring surface texture and roughness with a gage.

The most adaptableinput:
output:High-slope and large-part accessinput:
output:Increases the availability of data and the variety of measurement surfaces.Automatedmeasurement and analysisinput:
output:Reduce the complexity of measurement, the time required to obtain a result, and the handling of samples.input:
output:Outstandinginput:
output:user-friendly attributesinput:
output:Facilitate the attainment of expert results by operators of any experience level.input:
output:Configured to maximize productivity Both in the laboratory and on the factory floorinput:
output:The NPFLEX-1000 provides the most precise and repeatable surface texture and roughness metrology for nearly any precision manufacturing application.input:
output:The NPFLEX-1000 offers a distinctive array of critical benefits:input:
output:The ultimate compatibility of large-part and high-slope surfaces reduces the need for sample preparation and expands the number of measurement surfaces that can be accessed per part.input:
output:Operators of any level of experience are able to achieve expert results due to the exceptional ease of use.
