Ophthalmic Surgery Microscope

Exceptional optics with an exceptional depth of fieldinput:
output:Genuine Coaxial Lightinginput:
output:LED light source with an extended lifespaninput:
output:Video Camera with Integrated LensObjective of Apochromatisminput:
output:Operational record function that is practicalMounting systemAccessories

Efficient Magnification Control
Microscope

APO, objective F=200mm

Wide-field eyepieces with a 10x magnification are designed for individuals who wear eyeglasses.Adjustable eyecup with diopter adjustment +/– 5X-Y unitX-Y unit is powered by electricity, with an adjustable spherical radius of 40×40mm and a reset button.Motorized focus, 40mm, adjustable speed, reset button

LED illuminationRed Reflex illumination that is coaxial and integratedModification of light intensityLong-lasting LED illumination that is free of UV and IR radiationTwo unoccupied positions for filters that can be selected.Pitch modification Manual fine adjustment of the inclining mechanism +/– 15°

Waterproof foot switch with eight functions

Mounting system: Compact foot with four movable rollers and foot brakesThe maximum reach is 1070mm.Camera systemType: HD video recording system that is integratedVideo/photo resolution: 1920 x 1080 pixelsStorage time: 6 hours Accessories:Attachment of the assistant Stereo co-viewer and binoculars co-viewerBeam splitter: 50/50%, 70/30% (optional)Inclined angle of binoculars: 45°
