On-Platform, Tabletop Ultrasound System

22 MHz ultrasound is a fascinating instrument for in vivo skin thickness and density measurement, with a wide range of potential applications.input:
output:The Ultrascan UC 22 is an OEM device created specifically for C + K and our customers to complement the product line of skin testing parameters with a highly accurate, user-friendly, and cost-effective ultrasound device for cosmetic research.input:
output:The measurement is predicated on the fact that ultrasound waves enter the skin and are reflected in a manner that is specific to the various tissues. The reflected waves are converted into electrical impulses, which are displayed in a B-scan as an image with 256 distinct colors.input:
output:
With a frequency of 22 MHz, it is possible to observe the skin at a depth of 6-8 mm in high resolution. There are numerous benefits to the system:

An extremely precise and cost-effective device for conducting in-depth skin examinations.input:
output:The software is intuitive and easy to install, and it is only connected by a USBUC probe.

The probe is designed for effortless operation and executes all scans automatically without the user’s intervention. The transducer traverses the skin in a linear fashion.input:
output:A scan necessitates only water; there is no need for a messy gel application. Foils are not essential; however, they may be employed in conjunction with conventional ultrasound gel.input:
output:
Continuous live scans, rather than a single scan per measurement (with a video of 10 images per B-scan).Skin thickness in µm and skin density (ultrasound density in % and as a color value between 0 and 256 a. u.) are automatically measured between set lines for the total image and split for the epidermis/entrance echo and dermis.input:
output:Furthermore, measurements of the depth, width, and length of lines and area are also provided in freehand.
