Multipurpose Radiography Flat Panel Detector

By incorporating additional specifications and enhancements, the new series of Vivix-V panels enhances the quality that has been demonstrated thus far with the W series.

It is primarily employed in conventional bone rooms due to its compatibility with various generators. It is also a valuable tool for home radiology, as the panel can withstand a load of up to 400 kg, making it ideal for examinations of bedridden patients.

The new Vivix-V series' panels are integrated with VxVue software, which includes all Dicom functionalities. The software assists the examiner from the patient registration step through the acquisition process and the specific post-processing of each examination.

Depending on the customer's requirements and intended application, all panels are delivered with either a desktop or laptop computer.



The Vivix 3643VAW plus panel is incredibly lightweight, weighing only 3.3kg (including two batteries), and it is protected against dust and liquids by an IP67 rating.

The device is equipped with a USB-C fast charger as standard and can be upgraded to a desktop charging station upon request. Its battery life is 16 hours.

The battery charge and panel status can be verified using the OLED display.

It is capable of producing detailed images of exceptional quality due to the Cesium scintillator with a-Si TFT technology, 140 µm pixel pitch size, 16-bit grey scale, and high DQE.

The DQE is approximately 18% higher in the "plus" version.VxVue software, an advanced system that includes specific algorithms for each anatomical part, is included with the Vivix 3643VAW Plus panel. The results are exceptionally sharp, noise-free, and accurately contrasted as a result of the software and the high-quality construction and components of the panel.
