Mobile C-Arm

The ‘SD30 C’ surgical C-arm is a high-performance C-arm that employs flat panel detector technology. It has been specifically engineered for use in orthopaedics, trauma, and urology operating rooms, and is effortless to manipulate and position.input:
output:
It encompasses a broad range of surgical applications, including neurosurgery, vascular applications, endoscopy, vascular applications, urology, digestive, pain treatment, implantable chamber and pacemaker placement, and probe mounting.input:
output:
The most comprehensive version includes the following radiological techniques:input:
output:Continuous fluoroscopy

Fluoroscopy with pulses

Fluoroscopic imaging in a single session

Fluoroscopic imaging with minimal radiation

X-ray with cassetteinput:
output:The device is comprised of a mobile base on wheels, a rack that houses the low-voltage electronic components of the device, a “C” arm that carries the RX tube, and an image amplifier with a TV camera in its basic version.input:
output:The control panel for operational functions is located in the upper portion of the rack.input:
output:
The RX tube is equipped with either a 120 kV rotating anode or a 110 kV fixed anode, and the device is supplied with a 40 kHz RX generator.input:
output:A brightness amplifier with three zooms (3 fields) and a 9″ or 12″ size.input:
output:Usage Requirements: Intermittent workload with ongoing operations.input:
output:The console is equipped with a touch screen that displays pre-recorded exams and constants.
