Medical Device Galvanic Isolator

MLI-6015 network isolators from WERTH SYSTEMS are capable of withstanding 6000 VAC for one minute and can accommodate speeds of up to 1 Gigabit/s. The MLI-6000 is IEC/UL 60601-1 3.1 Edition certified and comes with a five-year warranty.input:
output:WERTH SYSTEMS MLI-6015 Network Isolators

The MLI-6015 is a cutting-edge Gigabit Network Isolator that has been specifically engineered for embedded or mobile solutions. The MLI-6015 is equipped with a distinctive tensile force limiter with overload release that, in the event of momentarily excessive traction, will automatically reject the connected network cable, thereby safeguarding the sensitive electronics from mechanical damage. It is manufactured in Germany under ISO13485 conditions, and each unit undergoes performance and isolation tests up to 6000 V AC. This guarantees a DEFECT RATE OF ZERO. The WERTH SYSTEMS MLI-6015 Network Isolators are designed to safeguard the patient and the operator from leakage currents, as well as a connected device from surges that may occur as a result of installation errors, aging, or moisture at the network interface. They protect the connected devices by attenuating low-frequency signal components, such as before ground loops. In this field of application, they satisfy the stringent standards established by the international standard UL/IEC 60601-1 for galvanic separation devices. The WERTH SYSTEMS MLI-6015 Isolators are capable of isolating a 6KV AC Voltage for a duration of one minute and a constant AC Voltage of a maximum of 400V.input:
output:safe – certified in accordance with the most recent ULJIEC 60601-1: 2012 3rd Edition standard ► enhanced reinforced isolation – 6000 V AC for 1 minute

► tensile force limiter with auto-release – reduces the risk of tripping over cables

► flexible – optional installation frames available
