Medical Autoclave

The Vakulab® HL is capable of addressing the challenging tasks associated with the production of sterile materials, such as solutions or filled syringes, as well as those found in production-related areas where the sterilization of fermenters, machine parts, clean room garments, filters, and other items necessitates customized solutions. This is due to its hygienic design and customer-specific special features.input:
output:Our response to the pharmaceutical industry’s stringent requirements for process and design reliability.input:
output:Suitable for the sterilization of solid and porous materials through the use of the pre-vacuum or pulsed vacuum process, followed by drying. Used in conjunction with the pre-vacuum process, liquids in containers that are either open or loosely sealed.input:
output:Using the steam/air mixture method (SAMM), liquids are stored in tightly sealed containers made from glass or heat-resistant material (exclusively with the steam/air mixture process option). Infectious substances (exclusively with the Exhaust air filter feature). The sterilizer is CE-marked in accordance with the Pressure Equipment Directive (PED) 2014/68/EU and the Machinery Directive 2006/42/EC. DIN 58950, AD 2000 Design of Pressure Vessels, and DIN EN 62304 Medical Device Software are the standards that are applicable.input:
output:Siemens controllerinput:
output:Display sizes of 12″ or 15″ or to the specifications of the customerinput:
output:Clamp or aseptic threaded connectionsFDA-compliant sealing materials and lubricants (21 CFR)The process sequence was regulated by the F0 value.input:
output:The filter housing and elements can be sterilized inline.input:
output:Active jacket coolinginput:
output:Cooling circuit connection and recirculation coolinginput:
output:Coil for coolingCompressed air sterile filtrationinput:
output:Air detectorAirtight isolationinput:
output:Fan for the steam/air mixture processEquipment package for “closed solutions”
