Medical Air Compressor

Oil-free serial-compressor stations with membrane dryersThe standard station is equipped with a control gear, oil-free compressor, and a quick coupling with a hose nozzle. The cooler and membrane dryer can be mounted on the top of the pressure receiver, which is equipped with an antibacterial internal coating, due to its compact design. Additional alternatives, including an operational hours meter and a fine filter, are accessible.

The membrane dryers’ technical date.
(Usable) Pressure range: 4 to 10 bar (60-145 psi)
Operating pressure: 7 bar (100 psi)Ambient temperature ranges from 5 to 40°C (41 to 104°F).
Dew point reduction: 35 Kelvin (-396 F)
Built-in microfilter with a 3 micron rating.Volume of vessel: U = 3 liters W = 10 litersT is equivalent to 25 liters, while H is equivalent to 55 liters.P is equivalent to 90 liters.
Dürr Technik provides modular compressor stations in addition to individual system solutions. Each of these is constructed from a variety of standard components in accordance with your specific specifications. Your benefit:You can gain from a price-performance ratio that is exceptional and a short delivery time.An internal anti-bacterial coating is included in our 10-, 25-, 55-, and 90-liter pressure receivers as a standard feature.If your application necessitates dry air, membrane dryers are available with varying pressure dew points. These dryers provide 100% continuous operation with minimal purge air consumption. The start-up behavior is optimized by a patented relief valve.
Certainly, the same high quality standards are applied to all modules as they are to our individual system solutions. Please do not hesitate to reach out to us.The operating conditions and operation site are significant factors in the module selection process.
