Medical Air Compression System

The compact design of Amico’s newly designed scroll systems enhances the overall serviceability and reduces the footprint. This configuration is suitable for compressors with a power output of 2 to 7.5 HP and is mounted horizontally on the receiver tank, thereby providing the highest possible space efficiency.input:
output:UL-listed control panel in a NEMA 12 enclosure featuring a 5.7″ touch screen displayAll alarms can be manually reset.

While any pump in the system is electrically operational, all control and alarm functions must remain activated.

Remote monitoring is enabled through Ethernet connectivity, which includes an embedded webpage that is password-protected for the remote adjustment of all operating parameters.V-belt-driven Oil-Less Rotary Scroll, single-stage, air-cooled construction, without the need for oil for operation (available in 120 or 145 psi configuration)

A-Frame, stackable scroll that enables the operation of two pumps simultaneously with a smaller footprint, thereby enabling a compact design.

A premium efficiency motor with a rotational speed of 3,600 revolutions

A method for removing the compressor for service or replacement without interrupting the system.Integral air treatment system with purge saving feature, NFPA 99 compliant assembly, dual desiccant air dryers, dual pre-filters, after-filters, pressure regulator valves, dew point monitor, CO monitor, and system safety valves.Fully pre-piped and pre-wired for single-point service connections. ASME certified.Rated for a minimum of 200 psig design pressure.The interior of the receiver is coated with a two-part epoxy that offers rust protection that is equivalent to or superior to that achieved through galvanizing it.
