Linear Actuator

Actuator, Electrak GX, 1 x 115 Vac, Dynamic Load: 1100 N, max stroke length: 6 inches, acme: 54 mm/s, control: hand windRobust and DependableAcme and Ball Screw Models
Dynamic Load up to 9kN/2000lbf Static Load up to 18kN/4000lbfOverload Clutch for Mid and End of Stroke Protection

Motor with Thermal Switch
Maintenance-freeIn order to operate the actuator, a capacitor is necessary. 115 Vac = 35 µF, p/n 9200-448-002, and 230 Vac = 10 µF, p/n 9200-448-003.The specification is as follows: – Value – Anti-rotation: No – Brake: Yes with ball screw and self-locking lead screwCertifications: CE Special Connector: Flying Leads End Play, Max: 1.016 mm / 0.040 in IP Rating, Dynamic: N/A IP Rating, Static: IP45

Manual Override: YesMaterial: Stainless Steel, Painted Zinc Alloynominal stroke – 152.40 mm / 6.00 inEnd-of-stroke protection is provided by an overload clutch. Mid-stroke protection is provided by an overload clutch.Screw Type: AcmeMaximum Temperature: 65°C / 149°FMinimum Temperature: -26°C / -15°FTemperature monitoring is not available.Voltage: 115 VacVoltage Tolerance: 102-130 VAC at 60 Hz

Current Draw Maximum: 2.8 amps

Weight: 6.200 kg / 13.669 lbs Control: None Feedback: None Serialization: No Smart Actuation: No Contains Liquids: No Returnable: No
