Laboratory Ozone Generator

The Sonimix 4001 is a primary transfer standard for ozone that can be used to generate ozone in conjunction with dry or wet air (optional). This allows for the calibration of ozone monitors at multiple locations. It produces an outflow of 3 Nl/min of air containing 10 to 1000 ppb O3, with a concentration that is more than 1% relative stable and reproducible. At a rate of 3 L/min, the extended range model produces 10-ppb to 10-ppm, and at a rate of 0.9 L/min, it produces 10-ppm to 35-ppm.

The Sonimix 4001 employs a pressure regulator, sonic nozzles, and an ozone generator that includes thermostatisation and regulation through UV light photometer measurement with atmospheric pressure and temperature corrections (US EPA method of UV absorption by ozone, Beer-Lambert law). The ozone analyzer is equipped with one reference UV light detector that alternates between measuring the UV intensity in the absence of ozone and the same UV light in the presence of generated ozone. The processor calculates the quantity of ozone produced using these two values.input:
output:-Accurate and stable to within 1% (relative)

-Calibration with dry and wet air-Included a novel LED photodetector- LCD display for ergonomic use – Air pollution monitoring-Ozone transfer laboratory br/>

Range-At a rate of 3 L/min, the concentration is increased from 10 to 1000 ppb in 1 ppb increments.-From 10 ppb to 10 ppm at a rate of 3 L/min and from 10 ppm to 35 ppm at a rate of 0.9 L/minThe principle of dilution-High-precision pressure regulators and sonic nozzlesAir dilution-Dry air from an external dry air source or internal zero air (option)input:
output:Gas flow that was produced

-3000 ml/min for range 1-900 ml/min for range 2input:
output:Precision+/- 2 ppb for 10 ppb to 100 ppb>100 ppb: 1.5% relativeinput:
output:Ozone Repeatability-An improvement over 1% relative
