Laboratory Colorimeter
| Applications | Laboratory |
| Other Characteristics | Automatic |
A novel LED technology that provides a wide range of spectral coverageinput:
output:Operates with either a 10 x 10 mm cuvette or a 14 mm test tube.input:
output:Suitable for use as a standalone measuring device or in Data Acquisition SystemsPresentationinput:
output:This colorimeter allows for measurements and dosages in transmission (0 to 100%) or absorbance, and it is extremely user-friendly, compact, and versatile.
It is capable of functioning as a standalone measuring device or can be connected to a Data Acquisition Interface (ExAO) via the integrated analog output.
The 1G-7 colorimeter is equipped with a single selection wheel and a large graphical display (6.6 cm).
The functions are easily accessible and the information is readily visible: wavelength selection, automatic zeroing (white) at the commencement of the manipulation, and the ability to switch between Transmittance and Absorbance.
The sample holder is capable of accommodating test tubes with a diameter of 14 mm or square section cuvettes with a size of 10 x 10 mm.
The 7 LEDs offer exceptional precision and a wide range of spectral coverage.input:
output:Specificationsinput:
output:Light source: LED
Measurement of seven wavelengths within the range of 470 to 660 nmRange of wavelengths: 470 nm, 525 nm, 570 nm, 590 nm, 605 nm, 626 nm, and 660 nm
Absorbance: -3 to +3 abs
Transmission: from 0 to 100% T
Resolution: 0.01 abs / 100.0%
Precision: ± 1.5%
Analog output is available on safety banana sockets with a diameter of 4 mm.-3V/3V is equivalent to -3 abs/3 abs of absorbance.0V/1V corresponds to a transmission rate of 0/100%.Power supply: mini USB power supply (supplied).
Dimensions: 160 x 120 x 70 mm.
