Hand-Held Ultrasound System
| Probe Type | Convex-Array, Linear-Array, Phased-Array |
| Ergonomics | Hand-Held |
| Options | All-In-One Probe, Wireless Probe |
| Application | For Multipurpose Ultrasound Imaging |
| Imaging Modes | B/W, Color Doppler |
The 3 in 1 protable wireless ultrasound scanner is designed to meet the requirements of all-day work, featuring an ultra-clear image and an ultra-long standby time. It includes a linear, convex, and phased array probe.
The most recent digital imaging technology offers high-definition images and precise data that surpass the capabilities of conventional desktop ultrasound machines.
The three-in-one probe is capable of seamlessly transitioning from shallow scan to deep scan without the need for a switch.Built-in independent Wi-Fi module that enables delay-free image transmission without the need for an external network, thereby reducing data transmission delay and enhancing image clarity.
The whole body examination is suitable for the ultra-wide frequency coverage of 2.5/3.5/5/7.5/10Mhz and the scanning depth of 20-305mm.The software is compatible with a variety of languages, including German, French, Italian, Portuguese, and Spanish. Additionally, it includes built-in measurement packages for heart rate, area, and other parameters. Multi-angle flipping of images is supported by the puncture function, as well as in-plane and out-plane flipping.
4200 mAh.Ultrasound scanning can be conducted at any time and in any location, and the treatment efficiency is enhanced by the 3.7V super-large lithium battery, which has a standby time of at least 12 hours and supports both wired and wireless charging.
Convex probe: The scanning depth is 90-305mm, and the center frequency is 3.5/5Mhz. It is appropriate for the scanning of abdominal and pelvic organs, FAST scanning, pleural effusion scanning, and lung ultrasound scanning.
Linear probe: The scanning depth is 20-80mm, and the center frequency is 7.5/10Mhz.Appropriate for the examination of superficial organs, including the breast, thyroid, and lymph nodes.Heart probe: The scanning depth is 90-160mm, and the center frequency is 2.5/5Mhz. Suitable for the ultrasonography of intracranial blood vessels and the cardiac ultrasonography of the heart and thoracic arteries.
