Hand-Held Ultrasound System
| Probe Type | Convex-Array |
| Ergonomics | Hand-Held |
| Options | All-In-One Probe, Wireless Probe |
| Application | For Multipurpose Ultrasound Imaging, For Gynecological And Obstetric Ultrasound Imaging, For Abdominal And Pelvic Ultrasound Imaging, For Cardiovascular Ultrasound Imaging, For Emergency Medicine Ultrasound Imaging, For Urology Ultrasound Imaging, For Breast Ultrasound Imaging, For Lung Ultrasound Imaging |
| Imaging Modes | B/W, Color Doppler |
The 3-in-1 wireless portable handheld ultrasound scanner is capable of scanning individuals at any time and in any location, including the emergency room, clinic, hospital ward, and operating theater.
It is a multipurpose handheld machine that is capable of performing a whole body ultrasound scan. It is a dual head probe that is a three-in-one device, featuring convex, linear, and cardiac capabilities.input:
output:Description:Consists of: – Dual 128
Frequency: – 3.5/5.0 MHz, 7.5/10 MHz, and 2.5/5.0 MHz- 90-305mm, 20-100mm, 90-160mmPreset 16+: – Abdomen, GYN, OB, Cardiac, Urology, Kidney, Lung, User1, User2
Pediatrics, Vascular, Carotid, Breast, Msk, Nerve, Thyroid, Small Parts User1 and User2input:
output:Host: – PC, tablet, or smartphone
Connectivity: – USB and WiFi
Parameters that can be modified by the software: – GN (gain), D (Depth), ENH (Enhancement), DR (Dynamic range), F (Frequency), FocusPos, PRF, WF, Mode, 8TGC, Biopsy, Annote, Page left/right/up/down.Dimensions: –
B: Distance, Angle, Area/Circumference, Trace, Length B+M: Heart rate, Time, Distance, LVID (LVIDd, LVIDs, EF, SV) GA(CRL,BPD,GS,FL,HC,AC)EFW(BPD,FL)B+PW: Velocity, Heart rate(2), S/D, and Depth.
Automatic Vessel Flow Measurement: PS, ED, TAMAX, TAMEAN, PI, RI, S/D, DIAM, FLinput:
output:
Frames of playback: – Optional: 100, 200, 500, and 1000Display Mode: – B, B+B, B/M, Color, PW, PDI, B+Color+PW
Grayscale Image Scale: 256 levelsType of WiFi: – Channel: 64 – Built-in WiFi, 802.11g/20MHz/2.4G/5G/450Mbpsframe: 24 frames per secondGain: 40-110 dBLanguage: English, Chinese, Russian, German, Italian, French, Ukrainian, Spanish, and PortugueseInfluence: – through the incorporation of a lithium batteryReplaceable battery: – Yes (by an engineer)Battery Life: 3 hours (working time), 12 hours (standby time)Charger: – Wireless charger, USB chargerWaterproof Rating: IPX5
