Fingertip Pulse Oximeter
| Configuration | Fingertip, Hand-Held, Wrist |
| Options | Computer-Based |
| Applications | For Animal Research |
| Accessories | With Separate Sensor |
| Patient Condition | For Sleep Apnea, Copd, For Asthma, For Pneumonia, For Snoring |
| Patient Type | Neonatal, Veterinary, For Animals |
MouseOx Plus is the second-generation product of STARR’s small animal pulse oximeter monitor in the United States. In a non-invasive manner, it is capable of measuring physiological parameters such as SpO2, heart rate, respiratory rate, pulse amplitude, and respiratory amplitude in small animals. A non-invasive sensor is employed to conduct all measurements, which is both efficient and precise. MouseOx is a device that is specifically engineered to measure the vital signs of rats and mice. It is suitable for both conscious and anesthetized animals.
Product Specifications
Intraoperative monitoring
Multiple vital signals are acquired by a non-invasive sensor.
Multichannels that can simultaneously monitor up to 16 animals
Cardiopulmonary function parameters are recorded in a variety of animals, including young rats, mice, rats, guinea pigs, and rabbits.Analog data outputheart rate
Monitor within the 90-900 BPM range
SpO2
Monitoring range: 0% to 100% arterial oxygen saturation;Error in monitoring: Less than 1.5% throughout the entire monitoring range;Respiratory rate
Monitoring reaction time: 0.72 secondsMonitoring reaction time: 1.7 seconds Monitoring range: 25-450 times per minutePulse amplitudeMonitoring range: Blood vessels with an inner diameter of 0 to 800 microns;Monitoring error: Less than 2.4% throughout the entire monitoring range.Monitoring reaction time: 0.72 secondsRespiratory amplitudeMonitoring frequency: 25 to 450 times per minute.Reaction time for monitoring: 1.7 seconds
Confirmed precision
