Dexa Bone Densitometer

Planar scanners, such as the Density series bone densitometers, are comprised of a fixed table and a “U” arm that moves longitudinally from the patient’s foot to their head (X axis).

An assembly generator – RX detector is mechanically aligned on the arm to ensure that the collimated x-ray beam perfectly centers the detector.

A transmission belt and gears are employed to facilitate the simultaneous movement of the generator and detector along the transverse direction (Y-axis).

In this manner, an X-Y scan is conducted in a specific patient region of interest.

The density series are the first bone densitometers to utilize the patented suspended arm architecture. Density’s design is both practical and aesthetically pleasing due to its one-piece solid aluminum frame. This innovative feature enables the open space beneath the table, which facilitates the cleaning and maintenance of the device. This, in turn, enhances the sanitation of the room in which the unit is installed, as there is no longer any dirt or dust concealed beneath the machine.input:
output:
The Density series densitometers minimize patient dose by adapting to the patient’s morphology and maintaining a high quality level of the images, which is achieved through their layout and an adaptive system of energy discrimination and current selection in the tube of the x-ray generator.input:
output:
The software has been meticulously engineered to be user-friendly and to have a remarkably gentle learning curve. It has been designed with the user in mind and includes a collection of automatic tools that facilitate the rapid and effortless execution of scans.
