Cryosurgery Unit

The CRYO-S ® Mini device is designed to ensure the local, rapid, and efficient freezing of tissues. It is equipped with a unique spraying cryoapplicator and a wide range of contact cryoapplicators. The spraying cryoapplicator, which allows for the continuous cooling adjustment, can freeze very small lesions (several cubic millimeters) as well as very large ones (several dozens cubic centimeters) by directly spraying liquid nitrous oxide onto the treated lesion. The device is employed for minor surgeries. The apparatus necessitates no electrical power source. The apparatus executes all functions pneumatically.input:
output:
The CRYO-S ® Mini device is operational within a matter of seconds. On pressing the foot switching controler, the probe’s tip attains the minimum temperature within 2 to 10 seconds. The pedal is released, resulting in a return to a temperature above 0°C within 3 to 3 seconds.

Specificationsinput:
output:
There is no requirement for an electrical supply.

Cooling medium (maintained in a steel cylinder under pressure).
Nitrous oxide (N2O).Carbon dioxide (medical CO2) Operating pressure.N2O – 3.5÷5 MPa

Carbon dioxide (medical CO2) – 5.5 MPa

Pressure gauge and adjustment system.
The internal circuit of the device is filled with gas under pressure after the cylinder valve is opened: shade of yellow End-piece cleaning pressure/blue: 0–20 bar Standard operating pressure (red) is 25–50 bar. Overpressure occurs at 60 to 80 bar.

Operation mode selector.

There are two operational modes: freezing and steady.

The foot switch controler is comfortable.

Cover for an estetic gas cylinder.

Four-way move trolley.Specializationsinput:
output:Dermatology
–

Cryosurgery is a treatment method that is employed to address a variety of benign, premalignant, and malignant skin lesions, either as a primary or alternative treatment.
