Ceiling-Mounted Air Diffuser

Air throw length control that is distinctive

Front plate with perforationsSimply choose between L02 or VAV functionality.

Specifically engineered for Demand Control Ventilation (DCV)

Easy installation

Noise at a low level

Bundle code RAPB is equivalent to RAPH + ATTD.input:
output:Optimix® L02 with a constant throw.

Optimix® VAV with flow rate control.

Throw or Vmin and Vmax can be easily adjusted.

Actuator that monitors the throw and flow rate in real time.Five duct connection sizes (100-250 mm).

One diffuser with a front plate measuring 595×595 mm and a connection of 315 mm.

Composed of steel sheets. The diffuser’s regulating components are composed of plastic.

Painted in the color RAL 9003. Additional colors and CleanVent coatings are available upon request.

Available in conjunction with the ATTD connection box (bundle code RAPB = RAPH + ATTD).input:
output:Specifications of the item

The pursuit of a harmonious equilibrium between energy efficiency, low noise, and comfort has been a consistent objective in the field of air delivery. Additionally, until recently, it was impossible to achieve a consistent cooling effect without draughts using supply air. No longer! The throw can be maintained by adjusting the airflow, and it is now feasible to achieve coolling effects of over 100 W/m2 with the use of Optimix LO2 control. Additionally, the installer can effortlessly reconfigure the identical unit as a combined VAV/Diffuser.input:
output:Features of the product

Display and dual functionality

The Optimix® active diffuser is a dual-purpose device that includes the Optimix L02 and Optimix VAV. Optimix® is a diffuser that includes a display. Throw or air flow adjustments are effortless and expedient. The display is instrumental in facilitating the precise and accurate adjustment. The selected throw or actual air flow rate is displayed on the display when ventilation is activated.input:
output:Optimix® L02 constant throw

The optimal throw can be easily adjusted to guarantee a comfortable air distribution without draught.
