Cardiac Stress Test Equipment

System developed to facilitate group rehabilitation that simultaneously guarantees an individual training regimen for each patient and ECG monitoring. It may be compatible with the ASPEL TRM-612 treadmill and the ASPEL CRG-601 cycloergometer. The set also enables the evaluation of the rehabilitation efficacy through the exercise capacity assessment module. This supervised training system enables the patient to be monitored electrocardiographically during physical exercise.input:
output:Specifications of technical nature

·The potential for the continuous recording of high-quality waveforms from 12 ECG leads.Compatibility between treadmills and ergometers,
·The comprehensive archiving of the tests that were conducted,· Continuous measurement of rhythm frequency and ST level and slope in 12 leads, ECG printout on a laser printer (normal paper, 3, 6, or 12 leads).
·ECG presentation in a variety of modes, including 3, 6, and 12 leads.·Significance of exceeding the established parameters (heart rate, ST level), ECG display manner (speed, amplification) can be easily and quickly altered.· A variety of filter types that enable the elimination of disturbances, including digital filters.It is feasible to configure the system in accordance with the needs of the user.·Capacity to compare changes in ECG waveforms,
· Possibility of recording resting ECGs for an extended period of time (up to 60 minutes),

· Customization of test protocols,

Standard equipment

·Medical Diagnostic Stand with 27″ LCD and external A4 printer

·USB key for ASTER softwareOptional:·ASPEL TRM-612 treadmill• ASPEL CRG-601 cycloergometer
