Body Plethysmograph

The device ensures the measurement of mechanical parameters of the pulmonary system. It is accessible to patients who are seated in a wheelchair (optional). The cabin’s double time constant enables tests to be conducted at normal breathing frequency and with panting. Additionally, the device offers a diffusion capacity test (optional).
A spacious cabin with a roof made of hardened glass and four transparent walls.
There is no moving component in the electro-magnetic door lock.Audiovisual metronome that can be programmed

The BTPS is automatically corrected based on the temperature, humidity, and pressure measurements in the cabin.Full automatic calibration and leakage testing
Communication system with an integrated microphone and speakerinput:
output:Modes of measurement
Thoracic gas volume

All components of airway resistance

Work of breathing

Maximum pressure of occlusionDynamic and static compliance (optional)
Active anterior nasal resistance (optional)

Diffusion capacity test (optional)Optional: Active posterior nasal resistanceForced ex- and inspiration
Static vital capacityVoluntary ventilation at its most extremeinput:
output:Parameters that were measuredTGV mode of the plethysmographTotal Lung Capacity (TLC)Thoracic Gas Volume (TGV)RV Residual VolumeThe ratio of RV to TLC in percentages is as follows:Raw Airway ResistanceAirway Resistance at Inspiration br/>
Rex Resistance of Airways at ExpirationRequested Equivalent ResistanceRaw – Specific Resistance of AirwaysSpecific Resistance of Airways at Inspiration (sRin)sRex – Specific Resistance of Airways at ExpirationGaw Conductance of AirwaysGin Conductance of Airways at InspirationGex Conductance of Airways at ExpirationSpecific Conductance of AirwayssGin Specific Conductance of Airways at Inspiration
