Binocular Colposcope

For the daily routine diagnosis, a colposcope is mounted on a mobile stand.input:
output:The optimal colposcope for daily routine diagnosis

The KP 3000 on a mobile stand is the optimal colposcope for routine daily diagnosis and is perfectly suited for this application. It satisfies high quality standards and captivates users with its compelling value proposition when paired with its accessories.

This colposcope is distinguished by its extensive selection of accessories, its versatility in daily medical practice, and its convenient and time-saving handling.input:
output:A Wide Selection of Accessoriesinput:
output:• LEDone lighting that is highly effective• Single magnification or three-step magnification changer

• Select from a straight or inclined tube

• Eyepieces and lenses that can be swapped out

• The T-handle can be affixed to either side.

• Implementation of a green filterData TechnicalRolling baseHeight: 600 mmTube that is straight

f = 125 mm f = 159 mmTube that is inclined

f = 125 mm and f = 159 mmObjective

f = 300 mm (f = 250 mm is an alternative).input:
output:Binoculars
WF 20x V with diopter compensation (dependent on the chosen WF of 16x V)input:
output:Swing in a green filterinput:
output:IlluminationContinuously adjustable LEDinput:
output:The T-handle can be affixed to either the left or right side.input:
output:Magnification with a 3-step changer and a tube with a diameter of 125 mm.Magnification factor: 0.63 – 1.0-1.6

Magnification: 6,5 – 10,0 – 16,0

Field of view Ø [mm] – 30,0 – 18,0 – 12,0

Eyepiece magnification WF 20 x, objective f = 250 mmMagnification factor: 0.63 – 1.0-1.6

Magnification: 5.0, 8.5, and 14.0

Field of view Ø [mm] – 36,0 – 22,0 – 15,0Eyepiece magnification WF 20 x, objective f = 300 mmMagnification without a changerMagnification – Field of View ØObjective f = 250 mm – 10.0 x300 mm – 8.5 x = objective f
