Ball Bearing Mill

A benchtop grinding mill that is compact and has the ability to crush with both shear and power.

The sample grinding process is transformed into a straightforward pre-treatment operation by the IQ MILL-2070. High-speed three-dimensional figure-8 motion is employed to achieve efficient crushing in a short amount of time by employing a specialized high-elastic belt with exceptional durability. This is the optimal sample treatment device for instrumental analysis, particularly in the crushing, stirring, and dispersing of polymer materials (patented in Japan).input:
output:IQ MILL-2070 grinding applications are illustrated. Please select “Griding applications” located at the bottom of this page.input:
output:Characteristics
1. User-friendly and straightforward to operateinput:
output:Simple operation for grinding samplesinput:
output:2. Grinding that is both rapid and effectiveinput:
output:Milling up to three samples simultaneously in the same programThe grinding time is significantly reduced as a result of the powerful impact and shear crushing capabilities.3. Cryo-milling liquid nitrogen cooling kitA compact design that enables the sample container to be precooled with liquid nitrogen prior to grinding.For the majority of materials, grinding is conducted at room temperature.Specificationsinput:
output:Ambient temperaturesinput:
output:Utilizing a refrigerant (e.g., liquid nitrogen), the temperature must be maintained at or below room temperature.input:
output:Establishing parametersinput:
output:Rotation speed (rpm): 50 to 3000 (stepless)input:
output:
Rotation time (seconds): 1 to 60 (10-second increments)input:
output:Pause time between cycles (seconds): 10 to 600 (10-second increment)input:
output:Rotation cycle: 1 to 10 (1 cycle step)Safety functioninput:
output:A combination of a manual lock and a double micro switchinput:
output:Dimensions and weight of the primary unit270 mm in width, 340 mm in depth, and 300 mm in height, with an approximate weight of 12 kg.input:
output:Power (50/60 Hz)100/120 VAC or 200/240 VAC (450 VA)
