Automatic Packaging Machine
| Type | Horizontal, In-Line |
| Operational Mode | Automatic, Continuous, Electronic, Servo-Driven, Semi-Automatic |
| Container Type | Bag, Film |
| Product Applications | Solids, For Medical Devices, For Sterile Materials, For Surgical Gauze |
| Options | With Touchscreen |
| Other Characteristics | High-Performance, High-Speed |
| Application Domain | Medical Industry, For Production, For Industrial Applications |
| Configuration | Floor-Standing, Compact |
The RDM-2020 is intended for the packaging of flat products, such as medical devices, at medium and high speeds.
The SIMOTION* axis management system from SIEMENS * regulates all movements through the use of independent servo-motors. The system is secured by three levels of access and is equipped with an audit trail system for production monitoring.input:
output:
The RDM-2020 is a practical, reliable, stable, and robust device that is constructed around a monobloc assembly that supports the primary components.
It is highly scalable and can be easily integrated into automated lines when assembled on an Item* profile frame.input:
output:
Bag length is adjustable, ranging from 80mm to 2 meters.
Bag width is adjustable, ranging from 60mm to 220mm (320mm in the W version).
Product height: up to 15mm
Heat-sealable laminates are compatible with the following materials:Aluminum, Plastic, and Paper
Cross Seal Type – Sealing bars that are either straight or chevron-shaped
Type of longitudinal sealing: Utilizing heated wheels
type of cut – by scissor blades
loading method – Bottom material, push tabs, or tape
