Automatic Media Preparation System

MyGenostics Inc. has developed the Automated NGS Library Preparation System (ELPS-01), which is employed for the preparation of libraries and the capture of targets prior to high-throughput sequencing (NGS). The system program is based on the standard production procedure and supports personalized programming and combination. It is easy to operate with the matching pre-closed reagent kit, which automatically completes library preparation, purification, capture, and gene quantification in a closed system for you. ELPS-01 is extensively employed in the detection of genetic diseases, tumors, pathogenic microorganisms, NIPT, and other NGS gene projects due to its ability to liberate experimental manpower and space on a large scale and its highly integrated, complex, and tedious processes.input:
output:Anti-Contaminationinput:
output:Operate the sample independently with the pre-closed reagent kit.input:
output:② User-friendly, completes the entire library and capture process automatically br/>


③ Access the system.In accordance with the majority of library construction and capture reagent brands.④Accurate and Dependableinput:
output:
A temperature monitor and high-precision pipetting system are employed to guarantee more precise and dependable outcomes.⑤Economicinput:
output:Reduce labor expenses

Product Name





AC 220V, 50Hz, 1000VA power supplyinput:
output:Dimensions: 500mm in length, 245mm in width, and 530mm in height.Net Weight: 40 kilogramsThroughput: Each machine supports a single sample, facilitating system multi-connection.input:
output:Pipetting: 20 μL to 100 μL, with a precision of ≤8% for 20 μL and ≤3% for 100 μL.input:
output:Temperature: PCR: 4℃-100℃; Refrigerated area: 2℃-8℃ Precision is less than 0.5 degrees Celsius.input:
output:Heating: ≥2.5℃/s for temperatures between 50 and 90℃; cooling: ≥2.0℃/s for temperatures between 90 and 50℃.input:
output:Duration of the experiment:Library preparation requires three hours, while Quick Capture requires six hours.input:
output:Software: Automated Library Preparation System software (ELPS-01)
