Automatic Glassware Washer

The LFRI rotary intermittent washer is a rotary washing machine that is fully automatic and operates in intermittent motion. It is designed to clean and wash brand-new containers, such as vials.input:
output:In order to facilitate the internal and external decontamination of containers, the rotary washing machine is designed to accommodate vials.Technical Characteristics
Design in accordance with the most recent FDA regulations and GMP standards.
Suitable for the washing of vials, bottles, and ampoules.Contact parts for containers and process fluids are constructed from AISI 316L stainless steel, silicone, or approved plastic materials.

Polycarbonate windows and a robust AISI 304 frame

Loading from a conveyor belt or turntable
High-performance transportation systemFully automatic, intermittent motion, with adjustable speedCustom internal/external washing and blowing layout with programmable times based on recipes9 grippers and 7 washing stations Easy size adjustment CFR21 Part 11 compliant PLC/HMI controlEasily integrated with a depyrogenation/sterilization tunnel.Maximum production rate: 6,000 pieces per hourWater recovery, silicone coating, and CIP/DIP/SIP are among the available options.input:
output:Water station that is directly accessible

The final rinsing/washing steps, whether internal or external, employ direct water.input:
output:The pressure switch with an alarm is employed to ensure that the direct water pressure prior to the needles is consistently sufficient.input:
output:Water is considered disposable due to its restricted consumption. It is feasible to modify the washing duration of each station.input:
output:Station for compressed air

The vials are dried between the washing steps and prior to discharge using dry and oil-free compressed air that is supplied by the customer.

The air is filtered by a 0.22 micron hydrophobic cartridge that is supplied by the customer.
