Automated Cell Counter

Intelligent image recognition, advanced optical imaging technology, and the trypan blue staining method are employed by the Automated Cell Counter LACR-A10 to provide information on cell count, viability, and diameter with a single click. Equipped with an amplification factor of 2.5 × 5.0 megapixels, this device employs both manual and autofocusing techniques. Designed with a counting area of 2.15 mm × 1.62 mm to allow for the insertion of a slide and the counting of cells in less than 9 seconds.

amplification factor – 2.5 x 5 megapixel

Focusing Method – Autofocusing and Manual FocusingCell Counting Area: 2.15 mm × 1.62 mmTypes of cells identified: primary cells, pollens, stem cells, cell lines, and beer yeast

Size of cells: 4 to 60 μm (Optimal: 7 to 60 μm)Cell Concentration Range: 104 to 107 cells/ml

Cell counting time is less than 9 seconds.Maximum data storage capacity is 1000, which includes reports and images.Dimensions (W × D × H)– 212 × 165 × 264 mmWeight: 3 kilogramsCharacteristics
Utilizes intelligent image recognition, advanced optical imaging technology, and the trypan blue staining method to facilitate automatic cell analysis. The BF channel clearly displays cell count and morphology.Equipped with an amplification factor of 2.5 × 5.0 megapixel for cell count.Employs both manual and autofocusing methods to count the cells.Designed to accommodate the slide for cell count, the counting area measures 2.15 mm × 1.62 mm.It is effortless to operate and counts cells in less than nine seconds, thereby reducing the amount of time spent on the job.Counts cells of various types with a cell concentration of 104 to 107 cells/ml with high precision.The optimal cell count ranges from 4 to 60 μm.The results are more stable and reliable due to the fast and accurate counting that occurs in a clear field of vision.A 1000-counting report and image storage capacity
