Animal Research Telemetry System
| Measured Parameter | Activity, Temperature, Heart Rate |
| Type Of Animal | For Large Animals, For Small Animals |
| Applications | For Animal Research, For Preclinical Research |
| Other Characteristics | Non-Invasive |
The physiological signal telemetry system employs wireless telemetry technology to bury the sensor within the body of experimental animals and wirelessly transmit physiological signals in real time. It is capable of measuring physiological parameters, including heart rate, body temperature, and activity level, in conscious and unrestrained rats, mice, rabbits, beagles, monkeys, and fish over an extended period.input:
output:This system can guarantee that animals are able to move freely within the cage without the need for anesthesia, thereby enabling the physiological signals to more accurately reflect the physiological conditions of animals in their natural state. Product Features:input:
output:Telemetry that is conducted wirelessly
Different indicators are measured using a variety of implanted sensor specifications.Body temperature, heart rate, and activity level are optional monitoring indicators.input:
output:Implantable sensors are wirelessly powered and do not require batteries.Long-term monitoring – It enables the continuous telemetry of experimental animals following the implantation of devices.Accurate and dependable reporting of physiological and behavioral data from conscious and unrestrained animalsThe system is capable of concurrently connecting up to 32 receivers, thereby enabling the completion of large-scale experiments.input:
output:The software is capable of setting experimental parameters, collecting data, performing data trend statistics, and outputting data. Technical parameters are also available.input:
output:Temperature measurement range: 33℃ to 41℃Temperature precision: ±0.1℃G2 implemented a sensor with dimensions of 15.5mm x 6.5mm and a weight of 1.1g.The size and weight of the G2 HR implanted sensor are 19.5mm x 3.5mm and 1.5g, respectively.
The sensor size and weight of the TA implanted are 23mm x 8mm and 1.6g, respectively.
HR implanted sensor size/weight: 26mm x 8mm / 2.2gHeart rate measurement range: 120-780 beats per minute
Activity level: Gross motor
