Anesthesia Ventilator

Summary
The Matrx™ Model 3000 is a pressure-limited, electronically controlled, time-cycled ventilator that replaces the breathing bag, ensuring the consistent and smooth delivery of anesthesia. The anasthesia ventilator Model 3000 is specifically engineered for veterinary practice, ensuring that each breath is delivered at a consistent volume, irrespective of patient compliance and airway resistance. Operational simplicity and convenience are achieved through user-friendly controls.The technician is able to assist with other procedures by replacing the breathing bag.Precise control of the anesthetic state enables the use of lower levels of anesthesia, which results in more responsive patients and a more cost-effective operation. Additionally, blood CO2 and pH levels are closer to normal.
With no tools necessary, interchangeable bellows can accommodate animals weighing from 1 kg to 300 kg.
The maximum working pressure limit (MWPL) is adjustable within the range of 10-60 cm H2O.

Any breath that exceeds the preset maximum or minimum is alerted by dual airway pressure alarms.Optional low supply gas alarms indicate that the gas pressure is below 35 psi.Respiratory rates ranging from 6 to 40 breaths per minute at inspiratory flow rates of 0 to 100 lpm.Tidal volumes range from 20 to 3,000 cubic centimeters.Built-in scavenging port
